ID.NR.59153 Elevator Board Elevator Part

 ID.NR.59153  Elevator Board  Elevator Part

• Main Control Board: Manages elevator operation (floor selection, car calls, safety signals).

• Door Control PCB: Handles door motor commands, safety sensors, and reopening logic.

• Drive/Inverter Interface: Connects to the VFD (Variable Frequency Drive) for motor control.

• Signal Processing Board: Processes inputs from buttons, sensors, or encoders.

 Key Specifications (Estimated)

• Voltage Rating: Likely 24VDC or 110/220VAC (depends on application).

• Communication: RS-485, CAN bus, or relay-based I/O.

• Compatibility:

  • Hyundai Micon 10/Micon 20 series (or similar).

  • Matches Hyundai-specific protocols (proprietary firmware).

Physical Characteristics

• Form Factor: PCB with mounting holes (possibly DIN rail or chassis-mounted).

• Connectors: Screw terminals or plug-in headers for wiring.

• LED Indicators: Status lights for power, errors, or communication.

 Common Failure Symptoms

• Elevator freezing between floors.

• Door operation faults (not opening/closing properly).

• Error codes related to control signals (e.g., Hyundai fault codes Exx series).

 Replacement & Service Notes

• OEM Part: Must be sourced from Hyundai Elevator or authorized distributors.

• Programming: May require firmware flashing or parameter sync (using HHT-WB100 tool).

• Cross-Reference: Check Hyundai manuals for equivalent boards (e.g., similar to NR.59152 or NR.59154).
